Exchange Table CNC Laser Cutting Machine

CNC exchange table laser cutting machine integrates advanced laser technology and high-precision CNC system,designed for efficient cutting of sheet metal.The equipment adopts the design of double table,which realizes the uninterrupted processing flow and greatly improves the production efficiency.Its intelligent control system makes operation easy whle reducing manual intervention and improving production safety.

Detail

ltem	4020 series	6025 series	8025 series	10025 series	12025 series
Processing format (LxW)	4000mmx2000mm	6000mmx2500mm	8000mm×2500mm	10000mm×2500mm	12000mm×2500mm
X-axis travel	4050mm	6050mm	8050mm	10050mm	12050mm
Y-axis travel	2030mm	2530mm	2530mm	2530mm	2530mm
Z-axis travel	300mm	300mm	300mm	300mm	300mm
X/Y axis repeated positioning accuracy	±0.03mm/m	±0.03mm/m	±0.03mm/m	±0.03mm/m	±0.03mm/m
X/Y axis maximum linkage speed	120m/min	80m/min	80m/min	80m/min	80m/min
Maximum acoeleration on the X/Y axis	1.2G	0.8G	0.8G	0.8G	0.8G
Recommended power range	6000W-20000W
